Dell PowerEdge R760 Rack Server

Description

The Dell PowerEdge R760 Rack Server is a powerful and versatile 2U, dual-socket server designed to handle demanding workloads across enterprise data centers. Engineered to deliver optimal performance for virtualization, AI/ML, database management, and software-defined storage, the R760 is built with the latest 4th Gen Intel® Xeon® Scalable processors and support for DDR5 memory and PCIe Gen5 technology. With flexible configurations and robust security features, it’s the ideal platform for organizations looking to future-proof their IT infrastructure.

The Dell PowerEdge R760 Rack Server is a high-performance, enterprise-level server designed for scalability, reliability, and efficiency in demanding IT environments. Here’s a full specification overview of the system:

Processor (CPU) – Dell PowerEdge R760 Rack Server

• Processor Family: 3rd Generation Intel Xeon Scalable Processors
• Processor Model: Supports Intel Xeon Platinum, Gold, Silver, and Bronze processors
• Core Count: Up to 40 cores per processor
• Processor Speed: Up to 3.8 GHz (depending on the processor model)

Memory – Dell PowerEdge R760 Rack Server

• Memory Type: DDR5, Registered DIMMs (RDIMM), Load-Reduced DIMMs (LRDIMM)
• Max Memory Capacity: Up to 3TB (depending on configuration)
• Memory Slots: Up to 32 DIMM slots

Storage

• Storage Controller: PERC H755, PERC H755N (optional)
• Storage Drives:
  • Supports both SAS, SATA, and NVMe drives
  • Up to 24 x 2.5” drives or 12 x 3.5” drives (depending on configuration)
• Maximum Storage: Up to 61.44TB (depending on drive type and configuration)

Networking

• Network Adapters: 2 x 10GbE ports (optional configurations for 25GbE, 100GbE)
• Ethernet Controller: Broadcom or Intel 10GbE / 25GbE options
• Optional Network Cards: Additional 10GbE, 25GbE, or 40GbE cards

Expansion Slots

• PCIe Slots: 8 PCIe 4.0 slots for expansion cards
  • 2 x PCIe 4.0 x16 slots
  • 4 x PCIe 4.0 x8 slots
  • 2 x PCIe 4.0 x16 slots (optional)

Power Supply

• Power Supply Type: Redundant, hot-plug power supplies (various wattages depending on configuration)
• Power Supply Capacity: 750W, 1100W, or 1600W depending on configuration

Operating System Compatibility

• Supported OS:
  • Windows Server
  • Red Hat Enterprise Linux
  • SUSE Linux Enterprise Server
  • VMware ESXi
  • Ubuntu Server
  • Citrix XenServer

Management

• Management Controller: iDRAC9 with Lifecycle Controller
• Remote Management: Support for remote management via iDRAC (IPMI 2.0, Redfish)

Form Factor

• Rackmount: 2U

Security Features

• TPM 2.0: Trusted Platform Module 2.0 for enhanced security
• Lockable bezel for physical security
• Secure Boot for system integrity
• System Lockdown for configuration protection

Cooling

• Fans: Redundant, hot-plug fans with advanced airflow control
• Temperature Sensors: Built-in sensors for optimal cooling and energy efficiency

Warranty and Support – Dell PowerEdge R760 Rack Server

• Warranty: 3-year ProSupport with Next Business Day (NBD) Onsite Service
• Support Options: Dell’s ProSupport and ProSupport Plus available for additional service packages

Use Cases

• Virtualized environments
• Data centers and cloud computing
• High-performance computing (HPC)
• Enterprise resource planning (ERP) applications
• Big data analytics
• Hyperconverged infrastructure (HCI)

Additional Features – Dell PowerEdge R760 Rack Server

• NVMe support: High-speed storage and lower latency for demanding applications
• Energy-efficient: Designed with energy-saving technologies to lower power consumption while maintaining performance
• Easy to Scale: Supports additional storage, memory, and networking components as your business grows.

The Dell PowerEdge R760 is optimized for flexibility and expansion, offering businesses the power they need to tackle complex workloads with ease.
