D-link NPP-6A1BLK242 24 Port Cat6A Unshielded Fully Loaded Punch Down

Description

D-link NPP-6A1BLK242 24 Port Cat6A Unshielded Fully Loaded Punch Down

• Eight-port RJ45 modules applied
• D stripes for identifying port allocations
• IDC compatible with 110 & Krone tool
• Terminating 4 pairs, 22-26 AWG, unshielded cable
• Improved cable management with an optional cable management bar (Simple type, or “r slot type)
• Universal labels Colour-coded for T568A and T568B wiring schemes

SPECIFICATIONS

• Identification: Silk Printing in White Color on Black Panel – D-link NPP-6A1BLK242 24 Port Cat6A Unshielded Fully Loaded Punch Down
• Panel:SPCC. 1.6 mm thickness with Black (RAL 9005) Colour painted
• RJ45 Jack: Housing: PC; Contact Bracket: PBT+Glass Fiber, UL94V-0, Black
• RJ45 Jack Contact:
• Material: Phosphor Bronze with Nickel plated
• Finish: 50 micro-inch Gold plated on Plug contact area
• IDC:Housing: PC, Terminal: Phosphor Bronze with Tin plated
• Jack Bracket Set: ABS
• Support Bar:SPCC, 1.6 mm thickness with Black(RAL 9005) Colour painted

PERFORMANCE

• T568A & T568B wiring scheme
• Insertion force: 20N max. (IEC 60603-7-4)
• Retention strength: 7.7 kg between jack and plug
• Operating temperature: -10oC to 60oC (ISO/IEC 11801, ANSI/TIA/EIA 568B.2)
• Life (mating cycles): Jack: 750 cycle’s min (ISO/IEC 11801, IEC 60603-7-4) IDC: suitable for 22-24 AWG stranded and solid wire, compatible with both 110& Krone punch down tools
• The Cat6A transmission performance is in compliance with the ANSI/TIA/EIA 568C.2 -1 standard
• Eight port modules applied
