Ubiquiti UniFi U6 LR Long-Range Access Point

The Ubiquiti UniFi U6 LR delivers an aggregate radio rate of up to 3.0 Gbps with 5 GHz (4×4 MU-MIMO and OFDMA) and 2.4 GHz 4×4 MIMO radios. The U6-LR seamlessly blends into any environment, and is capable of being mounted in indoor and semi-outdoor environments (IP54 rated).

Mechanical
Dimensions	Ø220 x 48 mm (Ø8.7 x 1.9″)
Weight	Without mount: 800 g (1.8 lb) With mount: 930 g (2.1 lb)
Enclosure material	Polycarbonate
Mount material	Stainless steel (SUS304)
Weatherproofing	IP54
Hardware
Networking interface	(1) GbE RJ45 port
Management interface	Ethernet Bluetooth
Power method	PoE+ Passive PoE, 48V
Power supply	UniFi PoE switch 48V, 0.5A PoE adapter (Not included)
Supported voltage range	44—57V DC
Max. power consumption	18.5W
Max. TX power 2.4 GHz 5 GHz 6 GHz	26 dBm 26 dBm –
MIMO 2.4 GHz 5 GHz 6 GHz	4 x 4 4 x 4 –
Throughput rate 2.4 GHz 5 GHz 6 GHz	600 Mbps 2400 Mbps –
Antenna gain 2.4 GHz 5 GHz 6 GHz	4 dBi 5.5 dBi –
LEDs	White/blue
Button	Factory reset
Mounting	Wall, ceiling (Included)
Operating temperature	-30 to 60° C (-22 to 140° F)
Operating humidity	5 to 95% noncondensing
Certifications	CE, FCC, IC
Software
WiFi standards	802.11a/b/g/n/ac/ax
Wireless security	WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3
BSSID	8 per radio
VLAN	802.1Q
Advanced QoS	Per-user rate limiting
Guest traffic isolation	Supported
Concurrent clients	350+
Supported Data Rates
802.11a	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b	1, 2, 5.5, 11 Mbps
802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)	6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)
802.11ac (WiFi 5)	6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)	7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
Application Requirements
UniFi Network	Version 6.0.34 and later
