Fortinet FortiGate 900G Firewall

Fortinet FortiGate 900G Firewall

System Performance and Capacity - Fortinet FortiGate 900G Firewall

• IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP):164 / 163 / 153 Gbps
• IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP):164 / 163 / 153 Gbps
• Firewall Latency (64 byte, UDP):3.78 / 2.5 μs*
• Firewall Throughput (Packet per Second):229.5 Mpps
• Concurrent Sessions (TCP):16 Million
• New Sessions/Second (TCP):720 000
• Firewall Policies:10 000
• IPsec VPN Throughput (512 byte)1:55 Gbps
• Gateway-to-Gateway IPsec VPN Tunnels:2000
• Client-to-Gateway IPsec VPN Tunnels:50 000
• SSL-VPN Throughput6:10 Gbps
• Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode):10 000
• SSL Inspection Throughput (IPS, avg HTTPS)3:16.7 Gbps
• SSL Inspection CPS (IPS, avg. HTTPS)3:18 000
• SSL Inspection Concurrent Session (IPS, avg HTTPS)3:1.6 Million
• Application Control Throughput (HTTP 64K)2:74.8 Gbps
• CAPWAP Throughput (HTTP 64K):70 Gbps
• Virtual Domains (Default / Maximum):10 / 10
• Maximum Number of FortiSwitches Supported:96
• Maximum Number of FortiAPs (Total / Tunnel):1024 / 512
• Maximum Number of FortiTokens:5000
• High Availability Configurations:Active-Active, Active-Passive, Clustering

Dimensions and Power

• Height x Width x Length (inches):1.5 x 17.0 x 15.0
• Height x Width x Length (mm):44.45 x 432 x 380
• Weight:15.98 lbs (FG-900G -7.25 kg) | 16.53 lbs (FG-901G-7.5 kg)
• Form Factor (supports EIA/non-EIA standards):Rack Mount, 1RU
• AC Power Supply:100"“240VAC, 50/60 Hz
• AC Current (Maximum):6A@100VAC
• Power Consumption (Average / Maximum):134 W / 252 W(FG-900G) | 144 W / 264 W(FG-901G)
• Heat Dissipation:861 BTU/h (FG-900G) | 902 BTU/h(FG-901G)
• Power Supply Efficiency Rating:80Plus Compliant
• Redundant Power Supplies (Hot Swappable):Yes (comes with 2PSU default)

Interfaces and Modules

• Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ Ultra Low Latency Slots:4
• Hardware Accelerated 10 GE SFP+ / GE SFP Slots:4
• Hardware Accelerated GE SFP Slots:8
• Hardware Accelerated GE RJ45 Slots:16
• 2.5 GE / GE HA Port:1
• GE Management Port:1
• USB Ports (Client / Server):2 / 2
• Console Port:1
• Onboard Storage:No(FG-900G) | 2x 480 GB(FG-901G)
• Trusted Platform Module (TPM):Yes
• Included Transceivers:2x SFP SX

System Performance - Enterprise Traffic Mix

• IPS Throughput²:26 Gbps
• NGFW Throughput^2,4:22 Gbps
• Threat Protection Throughput^2,5:20 Gbps

Operating Environment and Certifications - Fortinet FortiGate 900G Firewall

• Operating Temperature:32°F to 113°F (0°C to 45°C)
• Storage Temperature:-31°F to 158°F (-35°C to 70°C)
• Humidity:10% to 90% non-condensing
• Noise Level:58 dBA
• Forced Airflow:Side and Front to Back
• Operating Altitude:Up to 10 000 ft (3048 m)
• Compliance:FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
• Certifications:USGv6/IPv6
