Fortinet FortiGate 600F Firewall

Fortinet FortiGate 600F Firewall

System Performance and Capacity – Fortinet FortiGate 600F Firewall

• IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP):139 / 137.5 / 70 Gbps
• IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP):139 / 137.5 / 70 Gbps
• Firewall Latency (64 byte, UDP):4.12 μs / 2.5 μs*
• Firewall Throughput (Packet per Second):105 Mpps
• Concurrent Sessions (TCP):8 Million
• New Sessions/Second (TCP):550,000
• Firewall Policies:30,000
• IPsec VPN Throughput (512 byte):1.55 Gbps
• Gateway-to-Gateway IPsec VPN Tunnels:2,000
• Client-to-Gateway IPsec VPN Tunnels:50,000
• SSL-VPN Throughput:4.3 Gbps
• Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode):10,000
• SSL Inspection Throughput (IPS, avg. HTTPS):9 Gbps
• SSL Inspection CPS (IPS, avg. HTTPS):7,500
• SSL Inspection Concurrent Session (IPS, avg. HTTPS):840,000
• Application Control Throughput (HTTP 64K):32 Gbps
• CAPWAP Throughput (HTTP 64K):64.5 Gbps
• Virtual Domains (Default / Maximum):10 / 10
• Maximum Number of FortiSwitches Supported:96
• Maximum Number of FortiAPs (Total / Tunnel):1,024 / 512
• Maximum Number of FortiTokens:5,000
• High Availability Configurations:Active-Active, Active-Passive, Clustering

Interfaces and Modules

• Hardware Accelerated GE RJ45 Interfaces:16
• Hardware Accelerated GE SFP Slots:8
• Hardware Accelerated 10GE SFP+ / GE SFP Slots:4
• Hardware Accelerated 25GE SFP28 / 10GE SFP+ Ultra Low Latency Slots:4
• GE RJ45 MGMT/HA Ports:2
• USB Ports:2
• RJ45 Console Port:1
• Onboard Storage:0(FG-600F) | 2x 240 GB SSD(FG-601F)
• Included Transceivers:2x SFP (SX 1 GE)

System Performance* — Enterprise Traffic Mix

• IPS Throughput²:14 Gbps
• NGFW Throughput^2,4:11.5 Gbps
• Threat Protection Throughput^2,5:10.5 Gbps

Dimensions and Power

• Height x Width x Length (inches):1.75 x 17.0 x 15.0
• Height x Width x Length (mm):44.45 x 432 x 380
• Weight:15.6 lbs (FG-600F – 7.1 kg) | 16.2 lbs (FG-601F – 7.35 kg)
• Form Factor:Rack Mount, 1 RU (supports EIA/non-EIA standards)
• AC Power Consumption (Average / Maximum):169 W / 255 W(FG-600F) | 174 W / 260 W(FG-601F)
• AC Power Input:100–240V AC, 50/60Hz
• AC Current (Maximum):6A@100V
• Heat Dissipation:871 BTU/h (FG-600F)| 888 BTU/h(FG-601F)
• Redundant Power Supplies (Hot Swappable):Yes (comes with 2 PSU default)
• Power Supply Efficiency Rating:80Plus Compliant

Operating Environment and Certifications

• Operating Temperature:32°F to 104°F (0°C to 40°C)
• Storage Temperature:-31°F to 158°F (-35°C to 70°C)
• Humidity:5% to 90% non-condensing
• Noise Level:55 dBA
• Airflow:Side and Front to Back
• Operating Altitude:Up to 10,000 ft (3048 m)
• Compliance:FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
• Certifications:USGv6/IPv6
