Fortinet FortiGate 100F Firewall

Fortinet FortiGate 100F Firewall

System Performance and Capacity – Fortinet FortiGate 100F Firewall

• IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP):20 / 18 / 10 Gbps
• Firewall Latency (64 byte, UDP):4.97 μs
• Firewall Throughput (Packet per Second):15 Mpps
• Concurrent Sessions (TCP):1.5 Million
• New Sessions/Second (TCP):56 000
• Firewall Policies:10 000
• IPsec VPN Throughput (512 byte):11.5 Gbps
• Gateway-to-Gateway IPsec VPN Tunnels:2000
• Client-to-Gateway IPsec VPN Tunnels:16 000
• SSL-VPN Throughput:1 Gbps
• Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode):500
• SSL Inspection Throughput (IPS, avg. HTTPS):1 Gbps
• SSL Inspection CPS (IPS, avg. HTTPS):1800
• SSL Inspection Concurrent Session (IPS, avg. HTTPS):135 000
• Application Control Throughput (HTTP 64K):2.2 Gbps
• CAPWAP Throughput (HTTP 64K):15 Gbps
• Virtual Domains (Default / Maximum):10 / 10
• Maximum Number of FortiSwitches Supported:32
• Maximum Number of FortiAPs (Total / Tunnel):128 / 64
• Maximum Number of FortiTokens:5000
• High Availability Configurations:Active-Active, Active-Passive, Clustering

System Performance — Enterprise Traffic Mix

• IPS Throughput:2.6 Gbps
• NGFW Throughput ^{2, 4}:1.6 Gbps
• Threat Protection Throughput ^{2, 5}:1 Gbps

Interfaces and Modules

• Hardware Accelerated GE RJ45 Ports:12
• Hardware Accelerated GE RJ45 Management / HA / DMZ Ports:1 / 2 / 1
• Hardware Accelerated GE SFP Slots:4
• Hardware Accelerated 10 GE SFP+ FortiLink Slots (default):2
• GE RJ45 WAN Ports:2
• GE RJ45 or SFP Shared Ports *:4
• USB Port:1
• Console Port:1
• Onboard Storage:0(FORTIGATE 100F) | 1x 480 GB SSD(FORTIGATE 101F)
• Included Transceivers:0

Operating Environment and Certifications

• Operating Temperature:32°F to 104°F (0°C to 40°C)
• Storage Temperature:-31°F to 158°F (-35°C to 70°C)
• Humidity:10% to 90% non-condensing
• Noise Level:40.4 dBA
• Forced Airflow:Side to Back
• Operating Altitude:Up to 10,000 ft (3048 m)
• Compliance:FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
• Certifications:USGv6/IPv6

Dimensions and Power

• Height x Width x Length (inches):1.73 x 17 x 10
• Height x Width x Length (mm):44 x 432 x 254
• Weight:7.25 lbs (FORTIGATE 100F – 3.29 kg) | 7.56 lbs (FORTIGATE 101F – 3.43 kg)
• Form Factor (supports EIA/non-EIA standards):Rack Mount, 1 RU
• AC Power Supply:100–240V AC, 50/60 Hz
• Power Consumption (Average / Maximum):26.5 W / 29.5 W(FORTIGATE 100F) | 35.3 W / 39.1 W(FORTIGATE 101F)
• Current (Maximum):100V / 1A, 240V / 0.5A
• Heat Dissipation:100.6 BTU/h(FORTIGATE 100F) | 121.13 BTU/h(FORTIGATE 101F)
• Redundant Power Supplies:Yes (Default dual non-swappable AC PSU for 1+1 Redundancy)
• Power Supply Efficiency Rating:80Plus Compliant
